The HUBi 10k LIGHTING AND POWER SYSTEM
Introducing a reliable and robust Solar Hub to provide illumination and power where no grid power exists. Ideal for Camping, Fishing, Sheds, Greenhouses, etc. in fact anywhere you need light and power.
HUBi
The HUBi system works by collecting daylight and sunlight through its high performance crystalline solar panel and converting this to DC electricity which is fed directly into the Solar Hub containing a safe and lightweight Lithium battery pack. Smart internal electronics ensure that the system never gets overcharged and always extracts the maximum from its solar panel.
Unlike the HUBi 2k the HUBi 10k not only has a battery 5 times bigger but it is expandable, allowing you to connect up to 3 units together giving you a huge amount of power.
LUMi lighting
Both HUBi 2k and 10K are supplied with 2 LUMi lights. Each light can be switched via a button on the center point of the LUMi lens and also on the HUBi Solar Hub. Supplied with a 4m cable and hanging hook, each LUMi has a brightness of 40 lumens and this is capable of illuminating a 3m x 3m area. Using the very latest surface mounted LEDs ensures that LUMiās power consumption is kept to a minimum ensuring long burn times.
If more light is needed, up to four LUMIās can be powered from a single HUBi solar hub when the LUMi Light Splitter Cable accessory is purchased (sold separately).
SuppliedĀ with:
ā¦Ā 20w Solar Panel
ā¦Ā Solar Panel Stand
ā¦Ā 2 x Lumi 12v lights and mounting hooks
ā¦Ā Main HUBi 10A unit
ā¦Ā All connecting cables
ā¦ Two-year worldwide warranty
The Solar Hub has five output sockets that deliver power;
Technical Spec..
Solar Panel
- 20wĀ Premium Crystalline solar panel with corner protection
HUBi
- Lithium Ion battery for improved power delivery.
- 10A capacity
Data Panel
- LED lights showing charging, availableĀ power in battery, and power status (on/off)
Outputs
- 2 x LUMi lights outputs
- 2 x USB outputs (MAX 2A)
- 1 x Car Plug (MAX 3A)
Inputs
- Solar Panel charging input
- Mains / Expansion HUBi input
Size
- HUBi = 220mm x 146mm x 50mm
- Panel = 638mm x 278mm x 25mm
- LUMi = 120mm x 120mm x 120mm
Weight
- HUBi = 1.4Kg
- Panel = 2.13Kg
- LUMi =
Warranty
- 2 Years
Whats Included.
- HUBi 10k
- 20w solar panel including cable (2.5m)
- 2 x LUMi 12v Lights including cable (4m each)
- Each LUMi will illuminate a 3m x 3m area
- 2 x Light hooks for LUMi lights
- Solar Panel stand
- Instruction manual
